Criar aplicativos do Windows Forms que possam abrir arquivos do Excel com o clique de um botão é um requisito comum para aplicativos de desktop. Seja criando formulários de entrada de dados, geradores de relatórios ou ferramentas de processamento de arquivos, integrar operações do Excel com eventos de clique de botão é essencial.

Operações de arquivo do Excel ao clicar em um botão em formulários do Windows em C#

Cenários comuns

  • 📁 Abrir caixa de diálogo de arquivo do Excel: permitir que os usuários selecionem arquivos do Excel
  • 📊 Processar dados do Excel: Ler e exibir conteúdo do Excel
  • 💾 Exportar para Excel: Gere arquivos Excel a partir de dados de formulário
  • 🔄 Atualizar arquivos do Excel: Modificar arquivos do Excel existentes

Configurando o Projeto Windows Forms

Primeiro, crie um novo projeto do Windows Forms e adicione o Openize.OpenXML SDK:

<PackageReference Include="DocumentFormat.OpenXml" Version="3.2.0" />

using Openize.Cells;
using System;
using System.IO;
using System.Windows.Forms;

Exemplo 1: Abrir arquivo Excel com clique de botão

public partial class ExcelForm : Form
{
    private string selectedFilePath = "";

    public ExcelForm()
    {
        InitializeComponent();
    }

    // Button click to open file dialog
    private void btnOpenFile_Click(object sender, EventArgs e)
    {
        using (OpenFileDialog openFileDialog = new OpenFileDialog())
        {
            // Configure file dialog
            openFileDialog.Filter = "Excel Files|*.xlsx;*.xls|All Files|*.*";
            openFileDialog.Title = "Select Excel File";
            openFileDialog.InitialDirectory = Environment.GetFolderPath(Environment.SpecialFolder.Documents);

            if (openFileDialog.ShowDialog() == DialogResult.OK)
            {
                selectedFilePath = openFileDialog.FileName;
                lblFileName.Text = $"Selected: {Path.GetFileName(selectedFilePath)}";
                btnProcessFile.Enabled = true;

                // Immediately show file info
                DisplayFileInfo();
            }
        }
    }

    private void DisplayFileInfo()
    {
        try
        {
            using (var workbook = new Workbook(selectedFilePath))
            {
                var worksheet = workbook.Worksheets[0];

                lblWorksheetName.Text = $"Worksheet: {worksheet.Name}";
                lblRowCount.Text = $"Rows: {worksheet.GetRowCount()}";
                lblColumnCount.Text = $"Columns: {worksheet.GetColumnCount()}";
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error reading file info: {ex.Message}", "Error");
        }
    }
}

Exemplo 2: Processar dados do Excel e exibi-los no DataGridView

public partial class ExcelProcessorForm : Form
{
    // Button click to process Excel file
    private void btnProcessExcel_Click(object sender, EventArgs e)
    {
        if (string.IsNullOrEmpty(selectedFilePath))
        {
            MessageBox.Show("Please select an Excel file first.", "No File Selected");
            return;
        }

        try
        {
            ProcessExcelFile(selectedFilePath);
            MessageBox.Show("Excel file processed successfully!", "Success");
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error processing Excel file: {ex.Message}", "Error");
        }
    }

    private void ProcessExcelFile(string filePath)
    {
        using (var workbook = new Workbook(filePath))
        {
            var worksheet = workbook.Worksheets[0];

            // Clear existing data
            dataGridView1.Rows.Clear();
            dataGridView1.Columns.Clear();

            int rowCount = worksheet.GetRowCount();
            int colCount = worksheet.GetColumnCount();

            // Add columns to DataGridView
            for (int col = 1; col <= colCount; col++)
            {
                string headerText = worksheet.Cells[GetCellReference(1, col)].GetValue();
                if (string.IsNullOrEmpty(headerText))
                    headerText = $"Column {col}";

                dataGridView1.Columns.Add($"Col{col}", headerText);
            }

            // Add rows to DataGridView
            for (int row = 2; row <= rowCount; row++)
            {
                string[] rowData = new string[colCount];
                for (int col = 1; col <= colCount; col++)
                {
                    string cellRef = GetCellReference(row, col);
                    rowData[col - 1] = worksheet.Cells[cellRef].GetValue();
                }
                dataGridView1.Rows.Add(rowData);
            }

            // Update status
            lblStatus.Text = $"Loaded {rowCount - 1} rows and {colCount} columns";
        }
    }

    static string GetCellReference(int row, int col)
    {
        return $"{GetColumnLetter(col)}{row}";
    }

    static string GetColumnLetter(int columnNumber)
    {
        string columnLetter = string.Empty;
        while (columnNumber > 0)
        {
            columnNumber--;
            columnLetter = (char)('A' + columnNumber % 26) + columnLetter;
            columnNumber /= 26;
        }
        return columnLetter;
    }
}

Exemplo 3: Exportar dados do formulário para o Excel com um clique de botão

public partial class DataExportForm : Form
{
    // Button click to export data to Excel
    private void btnExportToExcel_Click(object sender, EventArgs e)
    {
        try
        {
            using (SaveFileDialog saveFileDialog = new SaveFileDialog())
            {
                saveFileDialog.Filter = "Excel Files|*.xlsx";
                saveFileDialog.Title = "Save Excel File";
                saveFileDialog.FileName = "ExportedData.xlsx";

                if (saveFileDialog.ShowDialog() == DialogResult.OK)
                {
                    ExportDataToExcel(saveFileDialog.FileName);
                    MessageBox.Show($"Data exported successfully to:\n{saveFileDialog.FileName}", "Export Complete");
                }
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error exporting data: {ex.Message}", "Export Error");
        }
    }

    private void ExportDataToExcel(string filePath)
    {
        using (var workbook = new Workbook())
        {
            var worksheet = workbook.Worksheets[0];
            worksheet.Name = "Exported Data";

            // Export form data
            worksheet.Cells["A1"].PutValue("Name");
            worksheet.Cells["B1"].PutValue("Email");
            worksheet.Cells["C1"].PutValue("Phone");
            worksheet.Cells["D1"].PutValue("Department");

            // Get data from form controls
            worksheet.Cells["A2"].PutValue(txtName.Text);
            worksheet.Cells["B2"].PutValue(txtEmail.Text);
            worksheet.Cells["C2"].PutValue(txtPhone.Text);
            worksheet.Cells["D2"].PutValue(cboDepartment.Text);

            // Export DataGridView data if available
            if (dataGridView1.Rows.Count > 0)
            {
                // Add headers from DataGridView
                for (int col = 0; col < dataGridView1.Columns.Count; col++)
                {
                    worksheet.Cells[GetCellReference(4, col + 1)].PutValue(dataGridView1.Columns[col].HeaderText);
                }

                // Add data rows
                for (int row = 0; row < dataGridView1.Rows.Count; row++)
                {
                    for (int col = 0; col < dataGridView1.Columns.Count; col++)
                    {
                        var cellValue = dataGridView1.Rows[row].Cells[col].Value?.ToString() ?? "";
                        worksheet.Cells[GetCellReference(row + 5, col + 1)].PutValue(cellValue);
                    }
                }
            }

            workbook.Save(filePath);
        }
    }
}

Exemplo 4: Formulário completo do Excel Manager

public partial class ExcelManagerForm : Form
{
    private string currentFilePath = "";

    public ExcelManagerForm()
    {
        InitializeComponent();
        UpdateButtonStates();
    }

    // Open Excel file
    private void btnOpen_Click(object sender, EventArgs e)
    {
        using (OpenFileDialog ofd = new OpenFileDialog())
        {
            ofd.Filter = "Excel Files|*.xlsx;*.xls";
            if (ofd.ShowDialog() == DialogResult.OK)
            {
                currentFilePath = ofd.FileName;
                LoadExcelFile();
                UpdateButtonStates();
            }
        }
    }

    // Create new Excel file
    private void btnNew_Click(object sender, EventArgs e)
    {
        try
        {
            using (var workbook = new Workbook())
            {
                var worksheet = workbook.Worksheets[0];
                worksheet.Name = "New Sheet";

                // Add some default content
                worksheet.Cells["A1"].PutValue("Column 1");
                worksheet.Cells["B1"].PutValue("Column 2");
                worksheet.Cells["C1"].PutValue("Column 3");

                using (SaveFileDialog sfd = new SaveFileDialog())
                {
                    sfd.Filter = "Excel Files|*.xlsx";
                    if (sfd.ShowDialog() == DialogResult.OK)
                    {
                        workbook.Save(sfd.FileName);
                        currentFilePath = sfd.FileName;
                        LoadExcelFile();
                        UpdateButtonStates();
                        MessageBox.Show("New Excel file created!", "Success");
                    }
                }
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error creating file: {ex.Message}", "Error");
        }
    }

    // Save changes to Excel file
    private void btnSave_Click(object sender, EventArgs e)
    {
        if (string.IsNullOrEmpty(currentFilePath))
        {
            MessageBox.Show("No file is currently open.", "No File");
            return;
        }

        try
        {
            SaveDataGridToExcel();
            MessageBox.Show("File saved successfully!", "Saved");
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error saving file: {ex.Message}", "Save Error");
        }
    }

    private void LoadExcelFile()
    {
        try
        {
            using (var workbook = new Workbook(currentFilePath))
            {
                var worksheet = workbook.Worksheets[0];

                // Load data into DataGridView
                dataGridView1.Rows.Clear();
                dataGridView1.Columns.Clear();

                int rowCount = worksheet.GetRowCount();
                int colCount = worksheet.GetColumnCount();

                // Add columns
                for (int col = 1; col <= colCount; col++)
                {
                    string header = worksheet.Cells[GetCellReference(1, col)].GetValue();
                    dataGridView1.Columns.Add($"Col{col}", string.IsNullOrEmpty(header) ? $"Column {col}" : header);
                }

                // Add rows
                for (int row = 2; row <= rowCount; row++)
                {
                    string[] rowData = new string[colCount];
                    for (int col = 1; col <= colCount; col++)
                    {
                        rowData[col - 1] = worksheet.Cells[GetCellReference(row, col)].GetValue();
                    }
                    dataGridView1.Rows.Add(rowData);
                }

                lblFileName.Text = Path.GetFileName(currentFilePath);
                lblStatus.Text = $"Loaded: {rowCount - 1} rows, {colCount} columns";
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error loading file: {ex.Message}", "Load Error");
        }
    }

    private void SaveDataGridToExcel()
    {
        using (var workbook = new Workbook(currentFilePath))
        {
            var worksheet = workbook.Worksheets[0];

            // Save headers
            for (int col = 0; col < dataGridView1.Columns.Count; col++)
            {
                worksheet.Cells[GetCellReference(1, col + 1)].PutValue(dataGridView1.Columns[col].HeaderText);
            }

            // Save data
            for (int row = 0; row < dataGridView1.Rows.Count; row++)
            {
                for (int col = 0; col < dataGridView1.Columns.Count; col++)
                {
                    var value = dataGridView1.Rows[row].Cells[col].Value?.ToString() ?? "";
                    worksheet.Cells[GetCellReference(row + 2, col + 1)].PutValue(value);
                }
            }

            workbook.Save();
        }
    }

    private void UpdateButtonStates()
    {
        bool hasFile = !string.IsNullOrEmpty(currentFilePath);
        btnSave.Enabled = hasFile;
        btnProcess.Enabled = hasFile;
    }
}

Melhores Práticas

  1. Sempre use Try-Catch: manipule operações de arquivo com segurança
  2. Validar caminhos de arquivo: Verifique se os arquivos existem antes do processamento
  3. Feedback do usuário: Mostrar progresso para operações longas
  4. Botões Habilitar/Desabilitar: Atualizar o estado da IU com base no contexto
  5. Filtros de arquivo: use filtros apropriados em caixas de diálogo

Conclusão

A integração de operações do Excel com cliques em botões do Windows Forms proporciona uma funcionalidade poderosa para desktop. O SDK Openize.OpenXML facilita:

  • ✅ Abrir arquivos do Excel por meio de caixas de diálogo
  • ✅ Processar e exibir dados do Excel
  • ✅ Exportar dados do formulário para o Excel
  • ✅ Crie interfaces completas de gerenciamento em Excel Comece a criar aplicativos profissionais do Windows Forms habilitados para Excel hoje mesmo!
