Créer des applications Windows Forms capables d’ouvrir des fichiers Excel d’un simple clic est une exigence courante pour les applications bureautiques. Que vous créiez des formulaires de saisie de données, des générateurs de rapports ou des outils de traitement de fichiers, l’intégration des opérations Excel aux événements de clic est essentielle.

Opérations sur les fichiers Excel en cliquant sur un bouton dans les formulaires Windows C#

Scénarios courants

  • 📁 Boîte de dialogue Ouvrir un fichier Excel : permet aux utilisateurs de sélectionner des fichiers Excel
  • 📊 Traiter les données Excel : Lire et afficher le contenu Excel
  • 💾 Exporter vers Excel : Générer des fichiers Excel à partir des données du formulaire
  • 🔄 Mettre à jour les fichiers Excel : Modifier les fichiers Excel existants

Configuration du projet Windows Forms

Tout d’abord, créez un nouveau projet Windows Forms et ajoutez le SDK Openize.OpenXML :

<PackageReference Include="DocumentFormat.OpenXml" Version="3.2.0" />

using Openize.Cells;
using System;
using System.IO;
using System.Windows.Forms;

Exemple 1 : Ouvrir un fichier Excel en cliquant sur un bouton

public partial class ExcelForm : Form
{
    private string selectedFilePath = "";

    public ExcelForm()
    {
        InitializeComponent();
    }

    // Button click to open file dialog
    private void btnOpenFile_Click(object sender, EventArgs e)
    {
        using (OpenFileDialog openFileDialog = new OpenFileDialog())
        {
            // Configure file dialog
            openFileDialog.Filter = "Excel Files|*.xlsx;*.xls|All Files|*.*";
            openFileDialog.Title = "Select Excel File";
            openFileDialog.InitialDirectory = Environment.GetFolderPath(Environment.SpecialFolder.Documents);

            if (openFileDialog.ShowDialog() == DialogResult.OK)
            {
                selectedFilePath = openFileDialog.FileName;
                lblFileName.Text = $"Selected: {Path.GetFileName(selectedFilePath)}";
                btnProcessFile.Enabled = true;

                // Immediately show file info
                DisplayFileInfo();
            }
        }
    }

    private void DisplayFileInfo()
    {
        try
        {
            using (var workbook = new Workbook(selectedFilePath))
            {
                var worksheet = workbook.Worksheets[0];

                lblWorksheetName.Text = $"Worksheet: {worksheet.Name}";
                lblRowCount.Text = $"Rows: {worksheet.GetRowCount()}";
                lblColumnCount.Text = $"Columns: {worksheet.GetColumnCount()}";
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error reading file info: {ex.Message}", "Error");
        }
    }
}

Exemple 2 : Traiter les données Excel et les afficher dans DataGridView

public partial class ExcelProcessorForm : Form
{
    // Button click to process Excel file
    private void btnProcessExcel_Click(object sender, EventArgs e)
    {
        if (string.IsNullOrEmpty(selectedFilePath))
        {
            MessageBox.Show("Please select an Excel file first.", "No File Selected");
            return;
        }

        try
        {
            ProcessExcelFile(selectedFilePath);
            MessageBox.Show("Excel file processed successfully!", "Success");
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error processing Excel file: {ex.Message}", "Error");
        }
    }

    private void ProcessExcelFile(string filePath)
    {
        using (var workbook = new Workbook(filePath))
        {
            var worksheet = workbook.Worksheets[0];

            // Clear existing data
            dataGridView1.Rows.Clear();
            dataGridView1.Columns.Clear();

            int rowCount = worksheet.GetRowCount();
            int colCount = worksheet.GetColumnCount();

            // Add columns to DataGridView
            for (int col = 1; col <= colCount; col++)
            {
                string headerText = worksheet.Cells[GetCellReference(1, col)].GetValue();
                if (string.IsNullOrEmpty(headerText))
                    headerText = $"Column {col}";

                dataGridView1.Columns.Add($"Col{col}", headerText);
            }

            // Add rows to DataGridView
            for (int row = 2; row <= rowCount; row++)
            {
                string[] rowData = new string[colCount];
                for (int col = 1; col <= colCount; col++)
                {
                    string cellRef = GetCellReference(row, col);
                    rowData[col - 1] = worksheet.Cells[cellRef].GetValue();
                }
                dataGridView1.Rows.Add(rowData);
            }

            // Update status
            lblStatus.Text = $"Loaded {rowCount - 1} rows and {colCount} columns";
        }
    }

    static string GetCellReference(int row, int col)
    {
        return $"{GetColumnLetter(col)}{row}";
    }

    static string GetColumnLetter(int columnNumber)
    {
        string columnLetter = string.Empty;
        while (columnNumber > 0)
        {
            columnNumber--;
            columnLetter = (char)('A' + columnNumber % 26) + columnLetter;
            columnNumber /= 26;
        }
        return columnLetter;
    }
}

Exemple 3 : Exporter les données d’un formulaire vers Excel en cliquant sur un bouton

public partial class DataExportForm : Form
{
    // Button click to export data to Excel
    private void btnExportToExcel_Click(object sender, EventArgs e)
    {
        try
        {
            using (SaveFileDialog saveFileDialog = new SaveFileDialog())
            {
                saveFileDialog.Filter = "Excel Files|*.xlsx";
                saveFileDialog.Title = "Save Excel File";
                saveFileDialog.FileName = "ExportedData.xlsx";

                if (saveFileDialog.ShowDialog() == DialogResult.OK)
                {
                    ExportDataToExcel(saveFileDialog.FileName);
                    MessageBox.Show($"Data exported successfully to:\n{saveFileDialog.FileName}", "Export Complete");
                }
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error exporting data: {ex.Message}", "Export Error");
        }
    }

    private void ExportDataToExcel(string filePath)
    {
        using (var workbook = new Workbook())
        {
            var worksheet = workbook.Worksheets[0];
            worksheet.Name = "Exported Data";

            // Export form data
            worksheet.Cells["A1"].PutValue("Name");
            worksheet.Cells["B1"].PutValue("Email");
            worksheet.Cells["C1"].PutValue("Phone");
            worksheet.Cells["D1"].PutValue("Department");

            // Get data from form controls
            worksheet.Cells["A2"].PutValue(txtName.Text);
            worksheet.Cells["B2"].PutValue(txtEmail.Text);
            worksheet.Cells["C2"].PutValue(txtPhone.Text);
            worksheet.Cells["D2"].PutValue(cboDepartment.Text);

            // Export DataGridView data if available
            if (dataGridView1.Rows.Count > 0)
            {
                // Add headers from DataGridView
                for (int col = 0; col < dataGridView1.Columns.Count; col++)
                {
                    worksheet.Cells[GetCellReference(4, col + 1)].PutValue(dataGridView1.Columns[col].HeaderText);
                }

                // Add data rows
                for (int row = 0; row < dataGridView1.Rows.Count; row++)
                {
                    for (int col = 0; col < dataGridView1.Columns.Count; col++)
                    {
                        var cellValue = dataGridView1.Rows[row].Cells[col].Value?.ToString() ?? "";
                        worksheet.Cells[GetCellReference(row + 5, col + 1)].PutValue(cellValue);
                    }
                }
            }

            workbook.Save(filePath);
        }
    }
}

Exemple 4 : Remplir le formulaire Excel Manager

public partial class ExcelManagerForm : Form
{
    private string currentFilePath = "";

    public ExcelManagerForm()
    {
        InitializeComponent();
        UpdateButtonStates();
    }

    // Open Excel file
    private void btnOpen_Click(object sender, EventArgs e)
    {
        using (OpenFileDialog ofd = new OpenFileDialog())
        {
            ofd.Filter = "Excel Files|*.xlsx;*.xls";
            if (ofd.ShowDialog() == DialogResult.OK)
            {
                currentFilePath = ofd.FileName;
                LoadExcelFile();
                UpdateButtonStates();
            }
        }
    }

    // Create new Excel file
    private void btnNew_Click(object sender, EventArgs e)
    {
        try
        {
            using (var workbook = new Workbook())
            {
                var worksheet = workbook.Worksheets[0];
                worksheet.Name = "New Sheet";

                // Add some default content
                worksheet.Cells["A1"].PutValue("Column 1");
                worksheet.Cells["B1"].PutValue("Column 2");
                worksheet.Cells["C1"].PutValue("Column 3");

                using (SaveFileDialog sfd = new SaveFileDialog())
                {
                    sfd.Filter = "Excel Files|*.xlsx";
                    if (sfd.ShowDialog() == DialogResult.OK)
                    {
                        workbook.Save(sfd.FileName);
                        currentFilePath = sfd.FileName;
                        LoadExcelFile();
                        UpdateButtonStates();
                        MessageBox.Show("New Excel file created!", "Success");
                    }
                }
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error creating file: {ex.Message}", "Error");
        }
    }

    // Save changes to Excel file
    private void btnSave_Click(object sender, EventArgs e)
    {
        if (string.IsNullOrEmpty(currentFilePath))
        {
            MessageBox.Show("No file is currently open.", "No File");
            return;
        }

        try
        {
            SaveDataGridToExcel();
            MessageBox.Show("File saved successfully!", "Saved");
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error saving file: {ex.Message}", "Save Error");
        }
    }

    private void LoadExcelFile()
    {
        try
        {
            using (var workbook = new Workbook(currentFilePath))
            {
                var worksheet = workbook.Worksheets[0];

                // Load data into DataGridView
                dataGridView1.Rows.Clear();
                dataGridView1.Columns.Clear();

                int rowCount = worksheet.GetRowCount();
                int colCount = worksheet.GetColumnCount();

                // Add columns
                for (int col = 1; col <= colCount; col++)
                {
                    string header = worksheet.Cells[GetCellReference(1, col)].GetValue();
                    dataGridView1.Columns.Add($"Col{col}", string.IsNullOrEmpty(header) ? $"Column {col}" : header);
                }

                // Add rows
                for (int row = 2; row <= rowCount; row++)
                {
                    string[] rowData = new string[colCount];
                    for (int col = 1; col <= colCount; col++)
                    {
                        rowData[col - 1] = worksheet.Cells[GetCellReference(row, col)].GetValue();
                    }
                    dataGridView1.Rows.Add(rowData);
                }

                lblFileName.Text = Path.GetFileName(currentFilePath);
                lblStatus.Text = $"Loaded: {rowCount - 1} rows, {colCount} columns";
            }
        }
        catch (Exception ex)
        {
            MessageBox.Show($"Error loading file: {ex.Message}", "Load Error");
        }
    }

    private void SaveDataGridToExcel()
    {
        using (var workbook = new Workbook(currentFilePath))
        {
            var worksheet = workbook.Worksheets[0];

            // Save headers
            for (int col = 0; col < dataGridView1.Columns.Count; col++)
            {
                worksheet.Cells[GetCellReference(1, col + 1)].PutValue(dataGridView1.Columns[col].HeaderText);
            }

            // Save data
            for (int row = 0; row < dataGridView1.Rows.Count; row++)
            {
                for (int col = 0; col < dataGridView1.Columns.Count; col++)
                {
                    var value = dataGridView1.Rows[row].Cells[col].Value?.ToString() ?? "";
                    worksheet.Cells[GetCellReference(row + 2, col + 1)].PutValue(value);
                }
            }

            workbook.Save();
        }
    }

    private void UpdateButtonStates()
    {
        bool hasFile = !string.IsNullOrEmpty(currentFilePath);
        btnSave.Enabled = hasFile;
        btnProcess.Enabled = hasFile;
    }
}

Meilleures pratiques

  1. Toujours utiliser Try-Catch : gérer les opérations sur les fichiers en toute sécurité
  2. Valider les chemins d’accès aux fichiers : vérifier si les fichiers existent avant le traitement
  3. Commentaires des utilisateurs : Afficher la progression des opérations longues
  4. Boutons Activer/Désactiver : mettre à jour l’état de l’interface utilisateur en fonction du contexte
  5. Filtres de fichiers : utilisez des filtres appropriés dans les boîtes de dialogue

Conclusion

L’intégration des opérations Excel aux clics des boutons Windows Forms offre de puissantes fonctionnalités bureautiques. Le SDK Openize.OpenXML simplifie :

  • ✅ Ouvrir des fichiers Excel via des boîtes de dialogue
  • ✅ Traiter et afficher les données Excel
  • ✅ Exporter les données du formulaire vers Excel
  • ✅ Créer des interfaces de gestion Excel complètes Commencez dès aujourd’hui à créer des applications Windows Forms professionnelles compatibles Excel !
